Highlights:

  • Flexible Inputs: The MP-M40 is equipped with 8 total inputs, including 4 mic/line inputs (Euroblock) and 4 RCA inputs (mono-summed RCA pairs), providing versatile connectivity options.
  • Ample Outputs: With 6 total outputs, including 4 balanced line outputs (Euroblock) and additional outputs for Music on Hold and Cue (phones), the MP-M40 ensures efficient signal routing and distribution.
  • Advanced Processing: Enjoy precise control over your audio with the 4-band parametric EQ, variable HPF and LPF, gate, and choice of Auto Gain Control (AGC) or Compressor for input processing, as well as 1/3 octave GEQ, anti-feedback filters, comp/limiter, ducker, and loudness for output processing.
  • Integrated Effects and RTA: Benefit from a multi-effects processor and a 1/3 octave RTA, allowing you to enhance your audio with various effects and monitor the audio spectrum.
  • Convenient Control: The MP-M40 can be easily controlled and managed through the optional MP-MFC wall controller and MP Install/Manage apps, offering user-friendly configuration and end-user control functions.


QSC MP-M40 Paging & Audio Processor

The MP-M40 is an advanced audio processor designed to provide exceptional control over your audio signals. With its flexible inputs and outputs, powerful processing capabilities, and convenient control options, the MP-M40 is a versatile solution for a wide range of applications, from small installations to larger venues.

Inputs: Total: 8
Mic/Line: 4 (Euroblock)
RCA: 4 (mono-summed RCA pairs)
Outputs: Total: 6
Line: 4 (Euroblock, balanced)
Music on Hold: 1 (Euroblock, transformer balanced)
Cue (phones): 1 (3.5 mm, stereo)
Input Processing: EQ: 4-band parametric EQ with high/low shelving option, variable 24/octave HPF and LPF
Dynamics: Gate, choice of Auto Gain Control (AGC) or Compressor
Output Processing: EQ: 1/3 octave GEQ
Anti-feedback Filters: 12-band variable notch filters
Dynamics: Comp/limiter, ducker, loudness
Delay: 100 msec
Loudspeaker Tunings: Factory: Intrinsic Correction™ voicing for QSC loudspeakers
User: 6-band parametric EQ, HPF & LPF (Linkwitz-Riley or Butterworth; 12, 18 or 24 dB/octave)
Effects & RTA: Effects: 1 multi-effects processor
RTA: 1/3 octave RTA
Control Accessories: MP-MFC: Optional wall controller
MP Install app: For configuration/design functions (for iOS/Android tablets, Windows and Mac OS PCs)
MP Manage app: For end user control functions (for iOS/Android tablets and smartphones)
Other Connections: Ethernet: 1 × RJ45 for connection to Wi-Fi router (user supplied)
MP-MFC ports: 2 × RJ45
GPI: 2 Inputs (Euroblock)
Net Dimensions (HWD): 45 × 483 × 356 mm
1.75 × 19 × 14-in
Weight: Shipping: 5.0 kg / 11 lb
Net: 3.2 kg / 7 lb
Phantom Power: All microphone inputs (+12 volts)
Power Requirements: TBD W, 100-240 VAC, 50-60 Hz, universal supply, IEC inlet
Indicators: Blue POWER LED, blue STATUS LED

The MP-M40 is designed to meet the demands of professional audio applications, providing precise control over your audio signals. With its comprehensive features and intuitive control options, the MP-M40 delivers outstanding performance, making it an ideal choice for installations, events, and more.
