JVC’s new DLA-RS2000 is a high quality native 4K home theater projector that features new, 0.69 inch D-ILA devices coupled with a 17-element, 15-group all glass 65mm lens. It offers high contrast, high brightness, and a host of color reproduction features that ensure dynamic and realistic images. Even those demanding movie theater quality reproduction will be impressed with the images produced by the DLA-RS2000.

  • 1,900 Lumens with High Power Lamp (PK-L2618U)
  • 80,000:1 Native (800,000:1 Dynamic) Contrast Ratio for deep blacks
  • Frame Adapt HDR (firmware 3.xx and up) dynamically adjusts tone mapping for best 4K HDR10 image quality with any source
  • New 0.69 inch native 4K D-ILA Devices (x3)
  • 17-element, 15-group all-glass 65mm diameter high quality lens
  • Two 18Gbps HDMI/HDCP 2.2 Compatible Inputs
  • ISF (Imaging Science Foundation) Licensed
  • HDR10 Compatibility with Auto Tone Mapping
  • Wide Color Gamut (Over 100% DCI P3)
  • Improved Clear Motion Drive with Motion Enhance
  • Improved Multiple Pixel Control (MPC) — MPC works with 4K60P (4:4:4) signals
  • Low Latency Mode improves picture, speeds operation, and reduces gaming/PC frame delays
  • New Installation Mode simplies setup and memorizes up to 10 customizable picture preferences
  • Control: Control4 SDDP / LAN / RS-232C / IR / 12V Screen Trigger Output / 3D Sync Output

Imaging device
0.69 in D-ILA Device (4096 × 2160) ×3

Native 4K
Yes

Resolution
4096 x 2160

Lens
2X Motorized 65 mm

Lens Shift
Motorized Shift±80% Vertical and ±34% Horizontal

Light Source
NSH 265W Lamp
(lamp life: approx. 4500 hours when the lamp is in Low mode)

Contrast Ratio
Native: 80,000:1 | Dynamic: 800,000:1

Input terminals
HDMI
2 (Full Speed 18Gbps HDMI/HDCP 2.2 Compatible w/HDR)

Digital Video Signal

480p, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz,
1080p/24 Hz, 1080p/50 Hz, 1080p/60 Hz, 3840×2160/24Hz,
3840×2160/25Hz, 3840×2160/30Hz, 3840×2160/50Hz*, 3840×2160/60Hz*
4096×2160/24Hz, 4096×2160/25Hz, 4096×2160/30Hz,
4096×2160/50Hz*, 4096×2160/60Hz*

3D Signal

Frame Packing
720p/50 Hz, 720p/60 Hz, 1080p/24 Hz

Side-by-Side
1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz,
1080p/50 Hz, 1080p/24 Hz, 720p/50 Hz, 720p/60 Hz

Top-and-Bottom
720p/50 Hz, 720p/60 Hz, 1080p/24 Hz

Dimensions

(WxHxD-inches)
19 5/8 x 9 1/4 x 19 1/2

Weight (net) (lbs)
43.56
