Description

Crosstalk: < Channel to Channel: < -80dB; Mute and Standby switch attenuation: > 100dB; Fader and FX/AUX/MON-Send attenuation: > 85dB;dB

Frequency Response (-3 dB) 15Hz to 70kHz

Power Requirement 100V to 240VAC, 50Hz to 60Hz

Power Consumption 35W

Height 4.31″ (109.6mm) Width 16.41″ (416.9mm) Depth 13.69″ (347.8mm)

Weight Net 12.79lbs (5.8kg)

Input Impedances MIC: 2㏀; CD In: 10㏀; All other inputs: > 15㏀;

Input Sensitivity MIC: -74dBu (155μV); LINE (Mono): -54dBu (1.55mV); LINE (Stereo): -34dBu (15.5mV); CD (Stereo): -34dBu (15.5mV);

Maximum SPL MIC inputs: +12dBu; Mono Line inputs: +31dBu; Stereo Line inputs: +30dBu; All other inputs: +22dBu; All other outputs: +22dBudB

MIC GAIN (Stereo) +10 to +60dB

MIDI Interface 5-pin DIN connector, In / Out

Operating Temperature Range +5 °C…+40 °C (40 °F…105 °F)

Output Impedances Phones: 47Ω; All other outputs: 75Ω (unbalanced), 150Ω (balanced)

Phantom Power 48VDC

Total Harmonic Distortion <0.005%
